Applications
- Scientific research, education (teaching, demonstration and academic exchanges)
- Digital laboratory, medical research
- Industrial visual (PCB examination, IC quality control)
- Medical treatment (pathological observation)
- Food (microbial colony observation and counting)
- Aerospace, military (high sophisticated weapons)
| Model No. | Sensor & Size(mm) | Pixel Size (µm) | G Sensitivity Dark Signal | FPS/Resolution | Binning | Exposure |
|---|---|---|---|---|---|---|
| HPS3CMOS45000CA | 45M/IMX492[C] 1.4″ (18.93×13.00) | 2.315×2.315 | 108mv with 1/30s 0.03mv with 1/30s | 8.1@8765×5616 30.0@4080×2808 8.1@7408×5556 33.0@4088×2808 10.4@8176×4320 34.7@4096×2160 62.5@2048×1080 86.5@1344×720 |
1×1(3:2) 2×2(3:2) 1×1 (4:3) 2×2(4:3) 1×1(17:9) 2×2(17:9) 3×3(17:9) 4×4(17:9) |
0.1ms~15s |
| HPS3CMOS45000CB | 45M/IMX492[C] 1.4″ (18.93×13.00) | 2.315×2.315 | 108mv with 1/30s 0.03mv with 1/30s |
8.1 @8176×5616(C) 30.0@4080×2808(M) 8.1 @7408×5556(C) 33.0@3696×2778(M) 10.4@8176×4320(C) 34. 7@4096×2160(M) 62.5@2048×1080(M) 86.5@1344×720(M) |
1×1(3:2) 2×2(3:2) 1×1(4:3) 2×2(4:3) 1×1(17:9) 2×2(17:9) 3×3(17:9) 4×4(17:9) |
0.1ms~15s |
| HPS3CMOS32000CA | 32M/IMX294[C] 1.15″ (12.96×12.96) td> | 2.315×2.315 | 108mv with 1/30s 0.03mv with 1/30s |
8.1 @5600×5600 30.0@2800×2800 30.0@1400×1400 |
1×1 2×2 4×4 |
0.1ms~15s |
| HPS3CMOS25000CA | 25M/IMX511[C] 1/2.3″ (5.519×5.519) td> | 1.12×1.12 | 96.3mv with 1/30s 0.1mv with 1/30s | 12@4928×4928 46@2464×2464 100@1648×1648 |
1×1 2×2 3×3 |
0.013ms~15s |
| HPS3CMOS21 000CA | 21M/IMX269[C] 4/3″ (17.4×13.0) |
3.3 x3.3 | 399mv with 1/30s 0.1mv with 1/30s |
17@5280×3954 17@3952×3952 56@2640×1976 67@1760×1316 192@584×438 |
1×1 1×1 2×2 3×3 9×9 |
0.1ms~15s |
| HPS3CMOS20400CA | 20.4M/IMX541[C] 1.1″ (12.32×12.32) |
2.74 x2.74 | 1574mv with 1/30s 0.15mv with 1/30s |
17.5@4496×4496 64.4@2240×2240 64.4@1120×1120 |
1×1 2×2 4×4 |
0.03ms~15s |
| HPS3CMOS20000CA | 20M/IMX183[C] 1″(13.06×8.76) |
2.4 x 2.4 | 462mv with 1/30s 0.21mv with 1/30s | 15@5440×3648 50@2736×1824 60@1824×1216 |
1×1 2×2 3×3 |
0.1ms~15s |
| HPS3CMOS20000CC | 20M/IMX183[C] 1″(13.06×8.76) |
2.4 x 2.4 | 462mv with 1/30s 0.21mv with 1/30s |
20@5440×3648 48@2736×1824 58@1824×1216 |
1×1 2×2 3×3 |
0.1ms~15s |
| HPS3CMOS18000CA | 18M/SONY Special[C] 1 /2.2 “(5.86×4.46) |
1.2 x 1.2 | 130mv with 1/30s 0.1mv with 1/30s |
17@4880×3720 40@2448×1836 50@1728×1296 |
1×1 2×2 3×3 |
0.1ms~15s |
| HPS3CMOS15600CA | 15.6M/SONY Special[C] 1.1″(13.0×13.0) |
3.3 x 3.3 | 399mv with 1/30s 0.1mv with 1/30s |
17@3952×3952 56@1976×1976 67@1316×1316 |
1×1 2×2 3×3 |
0.1ms~15s |
| HPS3CMOS12400CA | 12.4M/IMX545 [C,GS] 1.1″(11.22×8.22) |
2.74 x 2.74 | 1337mv with 1/30s 0.15mv with 1/30s |
28.2@4096×3000 100.9@2048×1500 100.9@1024×750 |
1×1 2×2 4×4 |
0.03ms~15s |
| HPS3CMOS12300CA | 12.3M/IMX304[C,GS] 1.1″(14.13×10.35) |
3.45 x 3.45 | 1146mv with 1/30s 0.1mv with 1/30s |
23.4@4096×3000 46.3@2048×1500 |
1×1 1×1 |
0.244ms~15s |
| HPS3CMOS12000CA | 12M/IMX226[C] 1/1.7″(7.40×5.55) |
1.85 x 1.85 | 280mv with 1/30s 0.1mv with 1/30s |
25@4000×3000 50@2048×1080 |
1×1 2×2 |
0.1ms~15s |
| HPS3CMOS12000CB | 12M/IMX577[C] 1/2″(6.29×4.71) |
1.55 x 1.55 | 250mv with 1/30s 0.25mv with 1/30s |
30@4056×3040 60@2028×1520 120@1014×760 |
1×1 2×2 4×4 |
0.1ms~5s |
| HPS3CMOS12000CC | 12M/IMX676[C] 1/1.6″(7.07×7.07) |
2.0 x 2.0 | 3637mv with 12 bit converted value (HCG) 0.15mv with 1/30s |
27@3536×3536 60@1768×1768 |
1×1 2×2 |
0.013ms~15s |
| HPS3CMOS9000CA | 9.0M/IMX305[C,GS] 1″(14.13×7.45) |
3.45 x 3.45 | 1146mv with 1/30s 0.15mv with 1/30s |
34@4096×2160 60@2048×1080 |
1×1 1×1 |
0.1ms~15s |
| HPS3CMOS8300CB | 8.3M/IMX334[C] 1/1.8″(7.68×4.32) |
2.0 x 2.0 | 505mv with 1/30s 0.1mv with 1/30s |
35@3840×2160 60@1920×1080 |
1×1 2×2 |
0.02ms~15s |
| HPS3CMOS8300CD | 8.3M/IMX585[C] 1/1.2″(11.14×6.26) |
2.9 x 2.9 | 5970(mV/lx/s) 0.13mv with 1/30s |
45@3840×2160 70@1920×1080 |
1×1 2×2 |
0.02ms~15s |
| HPS3CMOS8300CE | 8.3M/IMX678[C] 1/1.8″(7.68×4.32) |
2.0 x 2.0 | 3541(mV/lx/s) 0.15mv with 1/30s |
45@3840×2160 70@1920×1080 |
1×1 2×2 |
0.02ms~15s |
| HPS3CMOS8000CA | 8.0M/IMX294[C] 1.15″(13.00×13.00) |
4.63 x 4.63 | 419mv with 1/30s 0.12mv with 1/30s |
30@2808×2808(14bit) 139@1392×1392 139@696×696 |
1×1 2×2 4×4 |
0.1ms~15s |
| HPS3CMOS6300CA | 6.3M/IMX178[C] 1/1.8″(7.37×4.92) |
2.4 x 2.4 | 425mv with 1/30s 0.15mv with 1/30s |
30@3072×2048 38@1536×1024 |
1×1 2×2 |
0.02ms~15s |
| HPS3CMOS6300CB | 6.3M/IMX178[C] 1/1.8″(7.37×4.92) |
2.4 x 2.4 | 425mv with 1/30s 0.15mv with 1/30s |
59@3072×2048 59@1536x 1024 |
1×1 2×2 |
0.02ms~15s |
| HPS3CMOS51 00CA | 5.1M/IMX547[C] 1/1.8″ (6.71×5.61) td> | 2.74 x 2.74 | 1337mv with 1/30s 0.15mv with 1/30s |
63@2448×2048 208.4@1224×1024 |
1×1 2×2 |
0.03ms~15s |
| HPS3CMOS5000CA | 5.0M/IMX264[C,GS] 2/3″(8.45×7.07) |
3.45 x 3.45 | 1146mv with 1/30s 0.15mv with 1/30s |
35@2448×2048 50@1224×1024 |
1×1 1×1 |
0.1ms~15s |
| HPS3CMOS31 00CA | 3.1M/IMX265[C,GS] 1/1.8″(7.07×5.30) |
3.45 x 3.45 | 1146mv with 1/30s 0.15mv with 1/30s |
53@2048×1536 85@1024×768 |
1×1 1×1 |
0.1ms~15s |
| HPS3CMOS31 00CB | 3.1M/IMX123[C] 1/2.8″(5.12×3.84) |
2.5 x 2.5 | 600mv with 1/30s 0.15mv with 1/30s |
50@2048×1536 50@1920×1080 |
1×1 1×1 |
0.1ms~15s |
| HPS3CMOS21 00CA | 2.1M/IMX482[C] 1/1.2″(11.14×6.26) |
5.8 x 5.8 | 8935mv with 1/30s 0.6mv with 1 /30s |
96@1920×1080 | 1×1 | 14us~15s |
| HPS3CMOS2000CA | 2M/IMX385[C] 1/2″(7.2×4.05) td> | 3.75 x 3.75 | 2350mv with 1 /30s 0.15mvwith 1/30s |
125@1920×1080 | 1×1 | 0.01ms~15s |
| HPS3CMOS1500CA | 1.5M/IMX273[C,GS] 1/2.9″(4.966×3.726) |
3.45 x 3.45 | 1146mv with 1/30s 0.15mv with 1/30s |
164@1440×1080 320@720×540 |
1×1 2×2 |
0.1ms~15s |
| OTHER HARDWARE CONFIGURATION | |
|---|---|
| Spectral Range | 380–650nm (with IR-filter), for Monochromatic Camera, AR Is Used |
| White Balance | ROI White Balance / Manual Temp-Tint Adjustment |
| Color Rendering Technique | Ultra Fine Color Engine |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK (Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc) |
| ADC | 8 Bit / 14 Bit |
| Recording System | Still Picture and Movie |
| Cooling System* | Natural |
| SOFTWARE ENVIRONMENT | |
|---|---|
| Operating System | Support Microsoft Windows XP / Vista / 7 / 8 / 10 (32 & 64 bit), OS X (Mac OS X), Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher Memory: 2GB or More USB port: USB2.0 High-speed Port Display: 17″ or Larger CD-ROM |
| OPERATING ENVIRONMENT | |
|---|---|
| Operating Temperature | -10 °C ~ 50 °C |
| Storage Temperature | -20 °C ~ 60 °C |
| Operating Humidity | 30~80% RH |
| Storage Humidity | 10~60% RH |
| Power Supply | DC 5V over PC USB Port |
<
